SH113E automatic solidifying point tester is based on the national
standard ASTM D97 . It adopts modern advanced technology and
integrates mechanical, optical, electronic and computer technology.
It can automatically complete the test of cold filter point of
petroleum products. The instrument adopts photoelectric detection
technology and imported compression mechanism cold system to ensure
the required refrigeration depth.
Application: used for solidifying point analysis of dark petroleum
products, crude oil and other transparent or translucent petroleum
products.
ASTM D97 automatic solidifying point tester
ASTM D97 automatic condensation point tester
Solidifying Point Tester for Petroleum Products
ISO 3016,ASTM D97,DIN 52597,JIS K2269,IP 15,Soviet Union 20287-74.
Technical characteristic
1. Sensor:imported PT100 temperature sensor
2. Detection mode: imported photoelectric switch detection
3. Adopted color touch LCD
4. view historical data and print results
5. Export result: export results through U disk and store in the
computer
6.Display the trend of temperature over time
Technical Parameter
| Name | Detail information |
| Temperature control range | 30℃~ -70 ℃ |
| Refrigeration system | Imported double compressor refrigeration |
| Working power supply | AC220V ±10 ~ 50 Hz |
| Number of test samples | 1 |
| Temperature control accuracy | ±0.1 ℃ |
| Power consumption | 1500 W |
III. Technical parameters:
Meet the standard: GB/T510
Temperature measurement range: -70 ~ 50℃;
Number of test samples: 2 routes
Instrument size: 650*480*620mm
Instrument weight: 75kg
Temperature measuring element: PT100
Data management: can connect to the LIMS system
Data memory: microcomputer instrument memory can be expanded to 16
gigabytes.
Refrigeration mode: double compressor refrigeration
Cooling method: air cooling
Printing: dot matrix printing of 20 Chinese characters
Display: 128×64 Chinese characters display
Storage: 199 sets of historical data can be stored for easy query;
Result output: at the same time can be equipped with U disk output
function, output to the PC for long-term storage
Output format: The output format of the result USB flash disk is
CSV or EXCEL.
★ Data protection: with date password setting function.
Standard printing: standard micro printer automatic measurement
automatic thermal printing
★ Remote upgrade: with TCP network transmission function, can be
later software remote upgrade
Packing list of automatic freezing point instrument
| S/N | Name | Quantity | Unit | Remarks |
| 1 | Host | 1 | set | |
| 2 | Condensation point glass tube | 2 | set | Including inner tube and outer tube |
| 3 | Freezing point thermometer | 2 | piece | |
| 4 | power cord | 1 | piece | |
| 5 | Fuse tube | 1 | piece | |
| 6 | instruction manual | 1 | copy | |
| 7 | Packing list | 1 | copy | |
| 8 | Certificate warranty card | 1 | copy | |
Company Introduction
Shandong Shengtai Instruments Co., Ltd. is specialized in the
research and production of experimental testing instruments and
industrial testing instruments. It is a professional instrument
company integrating instrument research and development,
manufacturing, sales and service. Its products are widely used in
food, flour, grain and oil, Feed, electricity, petrochemical,
industrial oil, aerospace, coal quality and other industries.
For more than 10 years, Shengtai has always been adhering to the
"first-class service, customer first" as the purpose, "reasonable
price, honesty and trustworthiness" as the business policy. Adhere
to technical innovation, with rich knowledge of the technical team
and experienced, thoughtful after-sales service team.
Shengtai instrument as one of the most large-scale and competitive
enterprises in the industry, with the strength of technology
research and development, professional technical knowledge and
innovative design concept, in the model improvement, Significant
technical breakthrough has been achieved in the development of
function expansion and intelligent control system.
OUR service
After-sales service commitment, our company to sell the product
after-sales service commitment: warranty period of one year,
long-term technical support outside the warranty period. During the
warranty period, the seller shall bear the cost of the replacement
of the equipment, the freight and maintenance of the instrument;
outside the warranty period, the seller shall waive the maintenance
fee and charge only the cost of the basic materials and freight
charges when the instrument is malfunctioning and the seller shall
not charge the maintenance fee during the warranty period.
Packaging & Delivery
1. Out packing: Standard export wooden case.
2. Inner packing: With careful stretch film wrap product, hard wood
board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your
goods.
4.Port Any port of China
Lead Time :
| Quantity(Sets) | 1 - 1 | 2 - 5 | 6 - 10 | >10 |
| Est. Time(days) | 6 | 20 | 30 | To be negotiated |
