ST120H automatic eggshell strength tester is a new type of high precision
intelligent test instrument, which adopts modern mechanical design
concept and microcomputer processing technology to design
meticulously and reasonably. It adopts advanced components,
supporting parts, single chip microcomputer, and so on. Reasonable
structure and multi-function design, configuration of LCD Chinese
display, with the standard contained in the various parameters
testing, conversion, adjustment, display, memory, printing and
other functions.
Principle: the egg is fixed vertically between the upper and lower
measuring surface, the measuring surface moves relatively at a
certain speed, and the egg is crushed. The force required for the
breaking process is measured by sensors and recorded and displayed.
Product parameter
| Item | Parameter |
| Measuring range: | (0~200) N or (0~20) kg |
| Resolution: | 0.01N |
| Indication accuracy: | <± 1%, |
| Test speed: | (0.5~20) mm/s can be arbitrarily set or fixed 20 mm/s |
| Voltage: | 110~240V 50Hz |
| Dimension | 450mm×330mm×570mm |
| Weight | 25kg |
Product features
1,Mechatronics modern design concept, compact structure, nice
appearance, easy maintenance.
2,Adopting high precison weighing sensor fixed on upper platen, to
ensure colleting data rapidly and accurately.
3,Adopting high-speed ARM processor, to ensure the high degree of
automation and intelligentize, very easy to operate. It have power
data processing function, can get all the statistical results.
4,Display the pressure force and deflection in time on the LCD
display.
5,Finishing test, the measuring head can revert automatically.
6,Equipped with micro-printer, convenient to get the result.
Packing list
| S/N | Name | Quantity | Unit | Remarks |
| 1 | Host | 1 | set | |
| 2 | Egg buttress | 1 | piece | |
| 3 | Power cord | 1 | piece | |
| 4 | Fuse tube | 1 | piece | 10A in the safety seat |
| 5 | instruction manual | 1 | Copy | |
| 6 | Certificate warranty card | 1 | copy | |
Company Introduction
Shandong Shengtai Instruments Co., Ltd. is specialized in the
research and production of experimental testing instruments and
industrial testing instruments. It is a professional instrument
company integrating instrument research and development,
manufacturing, sales and service. Its products are widely used in
food, flour, grain and oil, Feed, electricity, petrochemical,
industrial oil, aerospace, coal quality and other industries.
For more than 10 years, Shengtai has always been adhering to the
"first-class service, customer first" as the purpose, "reasonable
price, honesty and trustworthiness" as the business policy. Adhere
to technical innovation, with rich knowledge of the technical team
and experienced, thoughtful after-sales service team.
Shengtai instrument as one of the most large-scale and competitive
enterprises in the industry, with the strength of technology
research and development, professional technical knowledge and
innovative design concept, in the model improvement, Significant
technical breakthrough has been achieved in the development of
function expansion and intelligent control system.
OUR service
After-sales service commitment, our company to sell the product
after-sales service commitment: warranty period of one year,
long-term technical support outside the warranty period. During the
warranty period, the seller shall bear the cost of the replacement
of the equipment, the freight and maintenance of the instrument;
outside the warranty period, the seller shall waive the maintenance
fee and charge only the cost of the basic materials and freight
charges when the instrument is malfunctioning and the seller shall
not charge the maintenance fee during the warranty period.
